VHC Shut-off Valve

VHC Shut-off Valve
    Enlargement
    Product Name : VHC Shut-off Valve
    Back
      • 1. The valve cut air source effectively and quickly.
      • 2. Hole lockable design to increase safety.
      • 3. Positioning mechanism ensures to cut air supply entirely.
      • 4. Available for connection with UC series.
      • 5. Identical with OSHA.
      •
      • OSHA regulation about installation standard for users:
      • When the worker repair and maintain machinery,shut-off valve can
      • exhaust residual pressure while air supply is shut down.In such repairing
      • or maintaining works,the shut-off valve operated by other careless people
      • may lead to downstream pipe pressurized and make cylinder or other
      • machines working accidentally, it will cause the worker injured. Therefore,
      • if shut-off valve is used for repairing or maintaining works,it should be locked
      • to prevent the worker injured from accidental operation by other people.
      • ※ZGUCFR/L-03MAB mounting bracket should be ordered for
      • connection with UC series (Please refer page A1-117 for mounting bracket.)
