PCL32-R013024-0700 TELESCOPE AIR CYLINDER (Double acting)

PCL32-R013024-0700 TELESCOPE AIR CYLINDER (Double acting)
    Enlargement
    Product Name : PCL32-R013024-0700 TELESCOPE AIR CYLINDER (Double acting)
    Back
    Feature:
    • Short cylinder body but  long stroke length, i.e. total stroke is about 1.6 times cylinder body length.
    • Telescoped dual stroke design.
    • Various mounting parts for selection : foot mounting; front/rear flange mounting; male/female clevis mounting.
